Model number |
F-1945 |
|
LCD & Touch Panel |
|
LCD Panel |
15-inch TFT |
|
MAX. Resolution |
1024 X 768 (Default) |
|
Brightness |
250 cd /m2 |
|
Touch Screen |
Resistive (RS232 type) |
|
System Configuration |
|
CPU |
Intel Celeron/ Dual Core/ Core 2 Duo Processor |
|
Chipset |
Intel 945GC+ ICH7 |
|
Main Memory |
240-Pin DDR2 RAM*2 slot, up to 4GB |
|
HDD |
1 x 3.5-inch SATA HDD |
|
Compact Flash Card |
1 x Bootable Compact Flash Card socket ( Type I/II ) |
|
I/O Ports |
|
Parallel Port |
1 x LPT Port ( SPP/EPP/ECP ). IRQ and address selectable |
|
Serial Port |
3 x DB-9 COM Ports. All with DC 5V/12V output on Pin 9 selectable |
|
USB Port |
6 x USB2.0 Ports (4 x rear, 2 x front) |
|
LAN Port |
1 x (10/100/1000M bps Auto) |
|
Keyboard / Mouse Port |
1 x PS/2 Keyboard, 1 x PS/2 Mouse |
|
Audio Port |
1 x MIC In |
|
Cash Drawer Port |
1 x RJ-11 Port (12V/24V selectable ) |
|
VGA Port |
1 x DB-15 connectors |
|
Speaker Output |
2 x 1W stereo Speaker |
|
DC Output |
1 x DC Jack 12V Output for 2nd Display |
|
Powering System |
|
Power Supply |
ATX 250W Internal Power Supply. AC 100 to 240V Full Range |
|
LED Indicators |
4 x LED Indicators ( Standby 5V / ATX on / HDD / LAN Status) |
|
Physical Dimensions |
|
Dimension |
350 ( L ) x 350 ( W ) x 350 ( H )mm |
|
Weight |
10Kg |
|
Safety & Environment |
|
Product Certification |
CE, FCC Certificated |
|
Operation Temperature |
0°C to 40°C |
|
Storage Temperature |
-25°C to 70°C |
|
OS Compatibility |
DOS / Windows XP / Windows 7 / WEPOS / POSReady 2009 |
